Mercury

Key Features

  • 16,000 Tests Records
  • 2.4" TFT Colour Touch Screen
  • Can connect Thermal Printer or Dot Matrix Printer by Bluetooth (optional)
  • Screening Mode and Standard Mode

Certificate

DOT certificate CE certificate ISO 9001 certificate FDA certificate

Specification


Sensor
Fuel Cell
Working Temperature
-10°C to 50°C
Storage Temperature
-25°C to 70°C
Size
14.5 x 6.6 x 3.3cm
Weight
267g (including battery)
Battery
4AA alkaline batteries
Battery Life
Over 3000 tests
Memory
16,000 tests records including all information
Display
2.4" TFT color touch screen (65,000 colors)
Sampling System
Automatically or manually takes a lung sample
Optional Power
Supply 12 volt car adapter or AC 6 volt adapter
Clock
Real time clock
Units of Measure
BrAC: mg/L, or any other units
Bac: grm%, mg/ml, mg/100ml, or any other units
Detection Range
0.00% BAC to 0.63% BAC
Accuracy
0 - 0.10% BAC: ±5%
0.10 - 0.15% BAC: ±8%
0.15 - 0.63% BAC: ±10%
GPS
5M range
Printer
Wireless Printer: Thermal or DOT Matrix
Connection Type
USB

Download


File Type Upload Date
Manual Download PDF 22 Feb 2021
Brochure Download PDF 25 Aug 2017

Accessory


A Sampling Cup is provided for screening test.


Sampling cup

Mouthpiece


Mouthpiece



Packing

accessory

Wireless Print

Bluetooth Thermal printer WPT-2B
Bluetooth Thermal Printer
Model: WPT-2B
Dot Matrix Printer
Model: WDMP2
